Nginx 实现同端口复用HTTPS/TLS业务

Nginx 实现同端口复用HTTPS/TLS业务

前置条件: nginx-1.15.2 以上

  1.15.2 版本新增了 $ssl_preread_protocol 变量,通过该变量可以使用 stream 反向代理时预先判断连接是否为SSL/TLS协议或者为非SSL/TLS协议,从而实现同一个端口来转发不同的业务,

  stream_ssl_preread模块检查初始ClientHello在SSL或TLS连接消息,并且提取其可用于管理连接几个值。$ssl_preread_protocol版本1.15.2中添加的变量从消息client_version字段中捕获最新的SSL / TLS版本号ClientHello。如果消息中supported_versions存在扩展名ClientHello,则变量设置为TLSv1.2/TLSv1.3

实例:在一台反向代理服务器上运行Nginx,并监听443端口,后端有两组服务,一个为HTTPS(开启TLS1.2/1.3)网站服务,另一个为SSH 服务,我们要实现这两组服务运行在同一个端口上(配置的443端口)--入口请求由Nginx自动区分。

为简便,我这时直接使用 docker环境

  • nginx 版本
# docker exec -it nginx nginx -V
nginx version: nginx/1.15.10
built by gcc 8.2.0 (Alpine 8.2.0)
built with OpenSSL 1.1.1b  26 Feb 2019
...<省略若干行>...
  • 目录文件
# tree ./nginx-with-L4-reuse/
./nginx-with-L4-reuse/
├── config
│   └── nginx
│       ├── conf.d
│       │   └── default.conf
│       ├── fastcgi.conf
│       ├── fastcgi_params
│       ├── mime.types
│       └── nginx.conf
└── docker-compose.yaml

3 directories, 6 files
  • docker-compose.yaml
# docker-compose.yaml
version: "2.4"
services:
  nginx:
    container_name: nginx
    image: nginx:alpine
    network_mode: host
    volumes:
      - ./config/nginx:/etc/nginx/:ro
    ports:
      - "443:443"
    restart: always
  • nginx.conf
user  nginx;
worker_processes  2;

error_log  /var/log/nginx/error.log warn;
pid        /var/run/nginx.pid;


events {
    worker_connections  1024;
}

stream {
    log_format stream '{"@access_time":"$time_iso8601",'
        '"clientip":"$remote_addr",'
        '"pid":$pid,'
        '"pro":"$protocol",'
        '"ssl_pro": "$ssl_preread_protocol"',
        '"pro":"$protocol",'
        '"stus":$status,'
        '"sent":$bytes_sent,'
        '"recv":$bytes_received,'
        '"sess_time":$session_time,'
        '"up_addr":"$upstream_addr",'
        '"up_sent":$upstream_bytes_sent,'
        '"up_recv":$upstream_bytes_received,'
        '"up_conn_time":$upstream_connect_time,'
        '"up_resp_time":"$upstream_first_byte_time",'
        '"up_sess_time":$upstream_session_time}';

    upstream ssh {
        server 192.168.50.212:22;
    }

    upstream web {
        server 192.168.50.215:443;
    }

    map $ssl_preread_protocol $upstream {
        default ssh;
        "TLSv1.2" web;
        "TLSv1.3" web;
    }

    # SSH and SSL on the same port
    server {
        listen 443;

        proxy_pass $upstream;
        ssl_preread on;
        access_log /var/log/nginx/stream_443.log stream;
    }
}
  • 启用nginx 服务
docker-compose up -d
  • 客户端分别发起HTTPSSSH请求

  • TLS

# curl -I -H "Host: xx.com" https://127.0.0.1/ -k
HTTP/1.1 200 OK
Server: nginx
Date: Wed, 03 Apr 2019 14:23:11 GMT
Content-Type: text/html
Content-Length: 561
Last-Modified: Tue, 19 Mar 2019 02:38:29 GMT
Connection: keep-alive
ETag: "5c905625-231"
Strict-Transport-Security: max-age=15768000
Accept-Ranges: bytes
* SSH
```
# ssh 127.0.0.1 -p 443

Last login: Wed Apr 3 21:54:52 2019 from 192.168.50.212
```

分别对应的请求日志

  • HTTPS
{
  "@access_time": "2019-04-03T13:54:45+00:00",
  "clientip": "127.0.0.1",
  "pid": 7,
  "pro": "TCP",
  "ssl_pro": "TLSv1.2",
  "stus": 200,
  "sent": 5384,
  "recv": 266,
  "sess_time": 0.122,
  "up_addr": "192.168.50.215:443",
  "up_sent": 423,
  "up_recv": 5384,
  "up_conn_time": 0.001,
  "up_resp_time": "0.001",
  "up_sess_time": 0.012
}
  • SSH
{
  "@access_time": "2019-04-03T13:54:53+00:00",
  "clientip": "127.0.0.1",
  "pid": 7,
  "pro": "TCP",
  "ssl_pro": "-",
  "stus": 200,
  "sent": 3115,
  "recv": 3888,
  "sess_time": 1.288,
  "up_addr": "192.168.50.212:22",
  "up_sent": 3911,
  "up_recv": 3115,
  "up_conn_time": 0,
  "up_resp_time": "0.008",
  "up_sess_time": 1.287
}

  $ssl_preread_protocol 实现IP层实现了不同业务配置,在某种需求上很有意义--虽然存在功能限制。然而Tengine-2.3.0 已经实现的IP层基于域名转发,或许这一特性会引入到Nginx。
