Traefik 体验笔记

traefik 与fabio 一样,也是一款现代流行的HTTP反向代理、负载均衡工具。功能要比fabio 更为丰富。

快速部署

  • docker-compose.yml
version: '3'

services:
  reverse-proxy:
    image: traefik # The official Traefik docker image
    command: --api --docker --docker.domain=docker.localhost # Enables the web UI and tells Traefik to listen to docker
    networks:
      - web
    labels:
      - traefik.enable=true
      - traefik.frontend.rule=Host:status.demo.com
      - traefik.port=8080
    ports:
      - "80:80"   # The HTTP port
      - "443:443" # The HTTPS port
    volumes:
      - /var/run/docker.sock:/var/run/docker.sock

  backend:
    image: nginx:alpine
    labels:
      - "traefik.frontend.rule=Host:demo.com"
      - "traefik.backend=backend01"
      - "traefik.port=80"
      - "traefik.enable=true"
      - "traefik.docker.network=web"
    networks:
      - web

networks:
  web:
    external: true
  • 启动Docker 实例
$ sudo docker-compose up

HTTPS 部署

  • 创建网络依赖
docker network create traefik_proxy
  • config/traefik/traefik.toml
#Traefik Global Configuration
debug = false
checkNewVersion = true
logLevel = "ERROR"

#Define the EntryPoint for HTTP and HTTPS
defaultEntryPoints = ["https","http"]


[entryPoints]
[entryPoints.http]
address = ":80"
[entryPoints.http.redirect]
entryPoint = "https"
[entryPoints.https]
address = ":443"
[entryPoints.https.tls]
  [[entryPoints.https.tls.certificates]]
    certFile = "/certs/ddos.com.pem"
    keyFile = "/certs/ddos.com.key"
  [entryPoints.eightzero]
  address = ":8081"

[api]
entrypoint = "eightzero"
#Enable retry sending a request if the network error
[retry]

#Define Docker Backend Configuration
[docker]
endpoint = "unix:///var/run/docker.sock"
domain = "docker.local"
watch = true
exposedbydefault = false
  • docker-compose.yml
version: '2.3'

services:
  reverse-proxy:
    image: traefik
    command: --api --docker --docker.domain=docker.localhost
    networks:
      - proxy
    ports:
      - "80:80"   # The HTTP port
      - "443:443" # The HTTPS port
    labels:
      - "traefik.enable=true"
      - "traefik.frontend.rule=Host:monitor.example.com"
      - "traefik.port=8080"
      - "traefik.frontend.auth.basic=admin:$$apr1$$IBj9Hfsd$$kf7vXLpY4/9XD365jcp/n1" # 带$符号的字符前面多加一个$
      - "traefik.frontend.entryPoints=https"
    volumes:
      - /var/run/docker.sock:/var/run/docker.sock
      - ./config/traefik/traefik.toml:/traefik.toml:rw
      - ./config/traefik/certs:/certs:ro
    restart:  on-failure

  backend:
    image: nginx:alpine
    labels:
      - "traefik.frontend.rule=Host:example.com"
      - "traefik.backend=backend"
      - "traefik.port=80"
      - "traefik.enable=true"
      - "traefik.passHostHeader=true"
      - "traefik.docker.network=traefik_proxy"
      - "traefik.frontend.entryPoints=http"
      - "traefik.backend.maxconn.amount=10"
      - "traefik.backend.maxconn.extractorfunc=client.ip"
      - "traefik.backend.loadbalancer.stickiness=true"
      - "traefik.frontend.headers.customResponseHeaders=Server:Traefik || X-Powered-By:vqiu.cn"
      #- "traefik.frontend.headers.SSLHost=example.com"
    networks:
      - proxy
    restart:  on-failure

  cadvisor:
    image: google/cadvisor:latest
    networks:
      proxy:
        aliases:
          - cadvisor
    labels:
      - "traefik.port=8080"
      - "traefik.frontend.rule=Host:cadvisor.example.com"
      - "traefik.frontend.auth.basic=admin:$$apr1$$IBj9Hfsd$$kf7vXLpY4/9XD365jcp/n1"
      - "traefik.backend=cadvisor"
      - "traefik.frontend.entryPoints=https"
      - "traefik.frontend.passHostHeader=true"
      - "traefik.frontend.whiteList.sourceRange=119.147.144.xx/29"
      - "traefik.frontend.whiteList.useXForwardedFor=true"
      - "traefik.frontend.headers.browserXSSFilter=true"
      - "traefik.frontend.headers.frameDeny=true"
      - "traefik.frontend.headers.customFrameOptionsValue=SAMEORIGIN"
      - "traefik.frontend.headers.STSSeconds=31536000"
      - "traefik.frontend.headers.STSIncludeSubdomains=true"
      - "traefik.frontend.headers.STSPreload=true"

    volumes:
      - /:/rootfs:ro
      - /var/run:/var/run:rw
      - /sys:/sys:ro
      - /var/lib/docker/:/var/lib/docker:ro
      - /dev/disk/:/dev/disk:ro
      - /etc/localtime:/etc/localtime:ro
    restart:  on-failure
networks:
  proxy:
    external:
      name: traefik_proxy
