Ansible批量部署华为CE交换机

有几台华为CE系列交换机上线，需要批量部署，印象中Ansible有专门针对华为CE的模块，于是就有了这篇笔记。

序

CE交换机侧主要配置，主要开启netconf

[CE] user-interface vty 0 4
       snetconf server enable
[CE] ssh user username service-type stelnet snetconf

一、安装

$ sudo yum install python-devel python2-pip

CE模块仅支持2.3
$ sudo pip2.7 install ansible==2.3.3
$ sudo pip2.7 install ncclient

二、安装CloudEngine模块

git clone https://github.com/HuaweiSwitch/CloudEngine-Ansible.git
cd CloudEngine-Ansible
sh install.sh

三、快速使用

使用命令模式查看vlan信息

$ ansible -m ce_command -a "commands='display vlan summary' transport='cli' host=192.168.30.101 port=xx username=xx password=xx" localhost --connection local

localhost | SUCCESS => {
    "changed": false,
    "stdout": [
        "Number of static VLAN: 15\nVLAN ID: 1 30 1111 1113 1115 1117 1119 1160 1211\n         to 1212 1221 to 1222 1231 to 1232 1501 \n\nNumber of dynamic VLAN: 0\nVLAN ID: \n\nNumber of service VLAN: 31\nVLAN ID: 4064 to 4094"
    ],
    "stdout_lines": [
        [
            "Number of static VLAN: 15",
            "VLAN ID: 1 30 1111 1113 1115 1117 1119 1160 1211",
            "         to 1212 1221 to 1222 1231 to 1232 1501 ",
            "",
            "Number of dynamic VLAN: 0",
            "VLAN ID: ",
            "",
            "Number of service VLAN: 31",
            "VLAN ID: 4064 to 4094"
        ]
    ]
}

ansible-playbook

• inventory

[all:vars]

[sr]
192.168.30.101 ansible_ssh_port=22 username=username password='password'
192.168.30.102 ansible_ssh_port=22 username=username password='password'

• playbook.yml

- name: CloudEngine command test
  hosts: sr
  connection: local
  gather_facts: no
  vars:
    cli:
      host: "{{ inventory_hostname }}"
      port: "{{ ansible_ssh_port }}"
      username: "{{ username }}"
      password: "{{ password }}"
      transport: cli
    list_of_vlans:
      - { id: 1989, name: "test" }

  tasks:
  - name: Create Vlan
    ce_vlan:
      vlan_id: "{{ item.id }}"
      name: "{{ item.name }}"
      state: absent
      provider: "{{ cli }}"
    with_items: "{{ list_of_vlans }}"

• 执行

$ ansible-playbook -i inventory playbook.yml

PLAY [CloudEngine command test] **********************************************************************************************************************************************************************************

TASK [Create Vlan] ***********************************************************************************************************************************************************************************************
ok: [192.168.30.102] => (item={u'id': 1989, u'name': u'test'})
ok: [192.168.30.101] => (item={u'id': 1989, u'name': u'test'})

PLAY RECAP *******************************************************************************************************************************************************************************************************
192.168.30.101             : ok=1    changed=0    unreachable=0    failed=0
192.168.30.102             : ok=1    changed=0    unreachable=0    failed=0

更多使用案例

https://github.com/HuaweiSwitch/CloudEngine-Ansible/tree/master/examples

报错1

fatal: [192.168.30.102]: FAILED! => {"changed": false, "failed": true, "msg": "unable to open shell. Please see: https://docs.ansible.com/ansible/network_debug_troubleshooting.html#unable-to-open-shell", "rc":255}

解决

export ANSIBLE_PARAMIKO_HOST_KEY_AUTO_ADD=True

或写入 ansible.cfg

[paramiko_connection]
host_key_auto_add = True

报错2

fatal: [192.168.30.102]: FAILED! => {"changed": false, "failed": true, "msg": "Error: Could not open connection, possibly due to unacceptable SSH subsystem name."}
fatal: [192.168.30.101]: FAILED! => {"changed": false, "failed": true, "msg": "Error: Could not open connection, possibly due to unacceptable SSH subsystem name."}

解决

在交换机侧配置将snetconf加入到service-type

ssh user username service-type stelnet snetconf

引用参考

• [1] https://www.jianshu.com/p/b2b3cffa972b
• [2] https://github.com/HuaweiSwitch/CloudEngine-Ansible
